Like a tree falling in the forest, if there is no one around to feel it, then an earthquake goes unnoticed. That doesn’t mean it didn’t happen.

Originally published in Temblor Earthquake News,  September 25, 2021.

Citation: Eakin, C. and Miller, M., 2021, Australia surprised by moderate quake, but rumbling is not unusual, Temblor http://doi.org/10.32858/temblor.208

Much to the surprise of many Australians, Australia does, indeed, have earthquakes. On the morning of Wednesday, September 22, a magnitude-5.9 earthquake struck approximately 130 km northeast of Melbourne, in the state of Victoria. Seismic waves were felt across several major cities including Melbourne, Canberra, Sydney and Adelaide, and as far south as Tasmania.

More than 40,000 people submitted accounts of their experiences during the quake to Geoscience Australia. This is the largest number of so called “felt reports” ever received by the site. However, Wednesday’s jolt, known as the Woods Point earthquake, did not surprise seismologists.

map of green land next to blue ocean. colored boxes
Map of gridded felt reports for the magnitude-5.9 earthquake near Mansfield, Victoria on Sept. 22, 2021. Credit: Geoscience Australia

Seismic sensors record around 100 earthquakes of magnitude-3 and above on the continent every year. Earthquakes of this size could be felt close to the epicenter if the quake does not occur too far below the surface. However, given the low population density of the vast Australian continent, very few people feel them. Fortunately, most of the larger magnitude earthquakes have so far occurred in remote locations, so the public is largely oblivious to their occurrence. Only when a quake strikes near a populated area do people take notice.

Earthquake patterns in Australia

Earthquakes in Australia are not freak events. In the last roughly 50 years, Australia has experienced seven onshore earthquakes of magnitude-5.9 or larger.

Moderate to large events (magnitude 5 to 6), although infrequent, tend to occur in the same locations as more common smaller magnitude events (magnitude 2 to 3). The small earthquakes indicate the presence of pre-existing faults and weak zones susceptible to rupture. Southeastern Australia, which includes Melbourne, Sydney and Canberra, is a region where these smaller magnitude events are relatively common. Thus, it is not surprising that a damaging earthquake could happen in this part of Victoria.

Across Australia, the distribution of seismicity is not uniform, but instead tends to concentrate within certain zones of increased activity. These zones include southeastern and southwestern Australia, as well as the Flinders Ranges, which extend northwards from Adelaide. Earthquakes occur across Tasmania, including near Hobart, as well as along the coast near Brisbane. A damaging earthquake could potentially strike near any of these capital cities.

yellow dots all over brown land surrounded by blue ocean
Map of all recorded earthquakes (yellow dots), notable events (red pins), and capital cities (black squares) across Australia. Data from Geoscience Australia

During the past 50 years, the most seismically active region of Australia has been in the southwestern corner of Western Australia. The 1968 magnitude-6.5 Meckering and 1979 magnitude-6.1 Cadoux earthquakes were the two largest ones to strike the area.

More recently, a magnitude-5.4 quake struck near Lake Muir in September 2018. It was followed by a magnitude-5.2 event two months later. The magnitude-5.4 event ruptured a seven km long scarp at the surface and weak shaking was felt in Perth, 250 km away.

Additional monitoring in Western Australia and South Australia

The Australian continent has been pieced together from different building blocks over its 3.8-billion-year geological history. The resulting cratons are relatively strong, but the remnants of ancient plate boundaries and associated faults tend to be weaker. As the continent responds to the stresses imposed by the surrounding active plate boundaries, deformation occurs and is focused in those zones of weakness. Identifying the weak zones and the associated earthquake patterns is one of the goals of current and future seismic deployments.

For example, in 2020 we and colleagues installed the temporary South West Australia Network (SWAN), which consists of 25 broadband seismometers spread across 320 by 270 miles (510 by 430 kilometers) of Western Australia. The array will remain until 2022. The goal of the project is to generate improved 3D images of the faults beneath the surface. With a denser array of seismic sensors, we can also more accurately locate future earthquakes, which will help scientists determine the hazard in the region (Miller et al., 2020).

In the first eight months of operation, the network located more than 1100 small-magnitude earthquakes. The vast majority of these would not have been detected by the national permanent network alone.

pink and gree dots on brown land surrounded by blue ocean
Currently recording seismic arrays (SWAN in pink and Lake Eyre Basin in cyan) designed to capture intra-plate earthquakes in two seismically active regions of Australia. These temporary networks are additionally supported by instrumentation in long-term operation from the Australian Seismometers in Schools (AuSiS) program (in orange) which provide real-time data and educational outreach within both cities and in rural communities (Australian National University, 2011). Data from AusPass.

Another seismic network is currently in operation surrounding Kati Thandi-Lake Eyre in South Australia called the Lake Eyre Basin seismic array (Eakin, 2018). Data from this temporary deployment has so far revealed more than 70 local earthquakes that would otherwise have gone undetected by the national network. These events appear to be associated with the edge of the Gawler Craton, one of the strong building blocks that formed part of the early Australian continent. The Lake Eyre Basin array is also designed to record events in the Simpson Desert, where a magnitude-6.4 earthquake occurred in 1941. Scientists know very little about this remote region, where very few people are around to feel the earth shake.

Acknowledgements: The SWAN and Lake Eyre Basin seismic arrays are supported by the AuScope – Earth Imaging program, as well as Australian Research Council grants LP180101118 and DE190100062.

References

Australian National University (ANU, Australia). (2011). Australian Seismometers in Schools [Data set]. International Federation of Digital Seismograph Networks. https://doi.org/10.7914/SN/S1

Eakin, C. (2018). Lake Eyre Basin [Data set]. International Federation of Digital Seismograph Networks. https://doi.org/10.7914/SN/5G_2018

Earthquakes@GA. Geoscience Australia, Canberra. http://pid.geoscience.gov.au/dataset/ga/121774

Miller, M., Allen, T., Murdie, R., Gessner, K., Yuan, H., & Kennett, B. (2020). South West Australia Network [Data set]. International Federation of Digital Seismograph Networks. https://doi.org/10.7914/SN/2P_2020
